Follow these steps to turn off the backlight feature: Menu > Settings > Display/Audio > Display Brightness > Standby set to ‘0’ > Accept
How do I turn off the Backlight on my 4iE Thermostat? Read More »
The Control Fault message might occur for several reasons. Please contact your electrician to have them test the resistance of your heating system based on the heating model that was installed in your floor using a digital multimeter set to a 200 ohms scale.
What Does the Control Fault Error Message Mean? Read More »
Start Wiring your Thermostat by Pulling Power from Terminals 2 and 5 Wiring the WSM-63 and ETO2 together is a great way to be able to control the WSM-63 timer panel with a pavement sensor. Pull the power from Terminals 2 and 5 and input into the L and N on the ETO2 controller.
How do I wire my WSM-63 to my ETO2 controller? Read More »
If you see the floor sensor error icon on the screen it means that your thermostat has been unable to detect the temperature of the floor. Please contact Warmup.
What Does the Error Message on my Tempo Mean? Read More »
The thermostat should be installed inside a square 4”x4” back box with a single mud ring mounted horizontally (also called plaster ring).
How do I Mount my Tempo Thermostat? Read More »
Wiring your Tempo thermostat is simple and straightforward.
How Do I Wire my Tempo Thermostat? Read More »
Programming your Warmup Tempo thermostat.
How-to: Programming Your Tempo Thermostat Read More »
The proper distance to space the mats should be 5 feet on center or 3ft between mats. Please refer to the installation manual for more details regarding your snowmelt installation.
Tire Tracks Installation: How Far Do I Space the Mats? Read More »
The maximum length Warmup recommends you can extend your snowmelt systems lead is 90′.
How Long Can You Extend the Lead on the Snowmelt System? Read More »
The megger is used as a quality control measure to test the insulation resistance to detect any fault in the heater cable jacket. Such leaks cannot be spotted with a regular ohmmeter and help spot any damage to the cable and cable jacket.
How do I test my system using a Megger (Mega-Ohmmeter)? Read More »
